Overview

Agras T20 is an all-inclusive spraying system that allows users to easily set flight and operation parameters. DJI’s Agras T20 sprays at a max rate of 6 L/min powered by 8 nozzles and high-volume pumps.

Equipped with an omnidirectional digital radar, the T20 is able to detect obstacles from all horizontal directions. The drone beats downtime and increases workflow significantly with a swappable spray tank and battery.

Applications

Agriculture

Tech Specs | Summary

• 20L Spray Tank
• 8 Nozzles with 7m Spray Width
• 6L/Minute Max Spray Rate
• 10 to 15 Minutes Max Hovering Time, Depending on Take-off Weight
• Up to 12 Hectares, Hourly Operation Efficiency
• Autonomous High-Precision Operation
• IP67 Rating for Core Modules
• Omnidirectional Digital Radar
• Real-Time Visual Monitoring System
• AI Intelligent Agriculture Engine

Tech Specs | Extra

• Total Weight (Excluding battery): 21.1 kg
• Standard Takeoff Weight: 42.6 kg
• Max Takeoff Weight: 47.5 kg (at sea level)
• Max Thrust-Weight Ratio: 1.70 (with a takeoff weight of 47.5 kg)
• Spray Tank Volume: Rated: 15.1 L, Full: 20 L
• Operating Payload: Rated:15.1 kg, Full:20 kg
• Nozzle Model: SX11001VS(standard) SX110015VS(optional) XR11002VS(optional)
• Quantity: 8
• Max Spray Rate: SX11001VS: 3.6 L/min SX110015VS: 4.8L/min XR11002VS: 6 L/min
• Droplet Size: SX11001VS: 130-250 μm SX110015VS: 170-265 μm XR11002VS: 190-300 μm (related to the actual working environment, spraying flow, etc.)
• Spray Width: 4-7 m (8 nozzles, at a height of 1.5 - 3 m above crops)
• Battery Model: AB3-18000mAh-51.8V
• Battery Weight: 6.4 kg (approximately)
